10Gbps 850nm VCSEL TOSA
Features:
Optica Communication
Rates up to 10Gbps
High coupling efficiency
Metal LC Receptacle package
Product Specifications:
Absolute Maximum Ratings(T=25℃)
|
Parameter |
Symbol |
Unit |
Min |
Max |
Note |
|
LD Forward Current |
IFLD |
mA |
|
10 |
|
|
LD Reverse Voltage |
VR |
V |
|
5 |
|
|
PD Forward Current |
IFPD |
mA |
|
10 |
|
|
Operating Temperature |
TOP |
℃ |
-10 |
85 |
|
|
Storage Temperature |
Tstg |
℃ |
-40 |
100 |
|
|
Solder Reflow Temperature |
Tsld |
℃ |
|
260 |
10 seconds max |
