3Gbps InGaAs PIN-TIA TO-CAN
Features:
·InGaAs PIN with trans-impedance
·High sensitivity
·Wide temperature range from-20℃ to +85℃
·3G SDI video
Product Specifications:
Absolute Maximum Ratings(T=25℃)
|
Parameter |
Symbol |
Unit |
Min |
Max |
Note |
|
Operating Temperature |
TOP |
℃ |
-20 |
85 |
|
|
Storage Temperature |
Tsyg |
℃ |
-40 |
100 |
|
|
Solder Reflow Temperature |
|
℃ |
|
260 |
10 seconds max |
|
Power Supply Voltage |
VP |
V |
0 |
4.5 |
|
